Pride Jazzy EVO 613Li
We're here to guide you through making the right decision to fit your needs.
Call 262-549-4900 today to speak to a product expert!
The Jazzy EVO 613 and Jazzy EVO 613Li measure in at an impressive 22 inches wide at the base and offer a 22-inch turning radius. Not only is it one of the most powerful power wheelchairs on the market, but it’s also one of the narrowest and most maneuverable.
The Jazzy EVO 613 series gives you all the best that Pride has to offer with patented Active-Trac Suspension and exclusive Mid-Wheel 6 Technology that provide you with a smoother, stable ride.
The Jazzy EVO 613 series of power wheelchairs with lithium batteries represent a philosophy we share here at Pride Mobility. If you’re not constantly improving, ever innovating, and pushing boundaries, you might as well fall behind.
The Jazzy EVO 613 stands on the shoulders of the industry-defining designs of its forebearers. Powerful lithium batteries last longer, charge faster and weigh less. The Jazzy EVO 613 has a futuristic design, with edgy lines and sharp colorways, giving you extra confidence.
* Each armrest adds 3-4" to the width of the seat. The minimum doorframe width needed is 25.25"; the width of the base.
Features:
300 lb. weight capacity
Narrow base width of only 22"
Maximum speed up to 5.1 mph
3" Ground clearance for
13" solid drive tires
Per charge range up to 21 miles with lithium-ion (200 lbs.)
Mid-wheel 6 Technology offers tight turning radius around doorways and corners
Pride's patented Active-Trac (ATX) Suspension ensures a smooth ride experience over uneven surfaces
Memory foam high-back seat with single seat post allows the user to swivel
Available depth-adjustable seat sizes: 16" W x16"-18" D, 18" W x 18"-20" D, 20" W x 18"-20"
Height, width, and angle adjustable armrests
Flip-up, height, angle, and depth adjustable foot platform
Removable matte-finish color-through shrouds
Specs:
| Specification | Details |
|---|---|
| Weight Capacity | 300 lbs |
| Speed | 5.1 mph |
| Operating Range | SLA: up to 14 miles (300 lbs), up to 17.1 miles (200 lbs); Lithium: up to 17.6 miles (300 lbs), up to 21 miles (200 lbs) |
| Turning Radius | 22" |
| Suspension | Active-Trac (ATX) |
| Ground Clearance | 3" at motor bracket |
| Drivetrain | Two motor, in-line, mid-wheel drive |
| Colors | Black (matte), White (matte), Red (matte), Iceberg Blue (matte), Robin's Egg Blue (matte), Sugar Plum (matte) |
| Charger | Off Board |
| Controller | 40A, PG GC3 |
| Battery | (1) 25V Lithium-iron phosphate |
| Braking System | Regenerative and electro-mechanical |
| Width | 22" |
| Length | 41" w/ footplate; 35" w/o footplate |
| Ground to Top of Seat | 20.5" – 22.5" |
| Weight (Assembled) | 189 lbs (SLA); 160.5 lbs (Lithium) |
| Heaviest Piece | 94 lbs |
| Seat Weight | 46 lbs (16"), 48 lbs (18"), 50 lbs (20") |
| Battery Weight | 18.5 lbs |
| Front Tires | 5" solid |
| Drive Wheels | Middle 13" solid |
| Casters | 5" |
| Seat Size (W x D) | 20" x 20" |
| Seat Back Height (No Headrest) | 16"x16"-18", 18"x18"-20", 20"x18"-20" |
| Warranty (Frame) | 5-year limited |
| Warranty (Drive Train) | 13-month limited |
| Warranty (Battery) | 13-month limited |
| Warranty (Electronics) | 13-month limited |
